Product Description
-
Intelligent PoE
-
Red Port Supports BT 90W
-
All-giga Ports
-
Smooth Transmission
-
Wide Working Temperature: –10 to 55°C (14°F to 131°F)
-
Plug and Play
-
Scene
-
Applicable to small and micro-scale monitoring networks such as office desktops, schools, hotels, supermarkets, hospitals
Product Specification
Brand |
Dahua |
Product Type |
PoE Switch |
Product Model |
DH-PFS3228-24GT-240 |
CErtification | |
Layer |
Layer 2 |
Managed |
No |
Switching Capacity |
52 Gbps |
Packet Forwarding Rate |
38.688 Mpps |
Packet Buffer Memory |
4 Mbit |
Mac Table Size |
8K |
Standards Compliance |
IEEE802.3, IEEE802.3u, IEEE802.3x, IEEE802.3ab, IEEE802.3z |
Hardware Feature | |
Standard Power Supply |
Yes |
PoE |
Yes |
Ethernet Port |
24 |
Optical Port |
2 |
Ethernet Port Rate |
1 Gbps |
Optical Port Rate |
1 Gbps |
Number Of Bussiness Card Slots |
Port 1–24: 24 × RJ45 10/100/1000 M (PoE) Port 25–26: 2 × RJ45 10/100/1000 (uplink) Port 27–28: 2 × SFP 1000 M (uplink) |
Power Supply |
100V AC–240V AC |
Operating Temperature |
–10°C to 55°C (14°F to 131°F) |
Operating Humidity |
10%–90% |
Storage Humidity |
5%–95% |
Power Consumption |
Idling: 8W Full load: 240W |
PoE | |
PoE Standard |
IEEE802.3af/ IEEE802.3at/ Hi-PoE/IEEE802.3bt |
PoE Budget |
Port 1–2≤90W, Port 3–24≤30W, total≤240W |
PoE Pin Assignment |
PoE/Hi-PoE: 1, 2, 4, 5 (V+), 3, 6, 7, 8 (V-) |
General | |
Esd |
Air discharge: 8kV Contact discharge: 6kV |
Thunderproof |
Common mode: 4kV Differential mode: 2kV |
Dimensions |
440 mm × 300 mm × 44 mm (17.32" × 11.81" × 1.73") |
Warranty |
As Per Manufacturer Terms and Condition |
