Dolphy Air Curtain Metal 560W DACN0005

Product Description

• Dolphy Air curtains that look like split AC comes with high quality international standards casing made in Metal body, which is sealed to resist dust going inside, and easy for cleaning & maintenance

• Blowers are made of high quality Metal to ensure less noise with toughness intensified high quality motor, low noise, overload protection and long life-span

• Air Speed is with high & low two switch of speeds

• They are used in various industries such Food Processing Industries Pharmaceutical ,Hotel & Restaurants ,Hospitals/Laboratories ,Malls, Supermarket, Showrooms, Theaters /Auditoriums ,Clean Room , Cold Storage ,Computer Rooms & Facilities etc

• Features

• Fireproof/rust resistant high-tech aluminum and Metal case reduces the possibility of damaging

• Easy to clean and protect your healthy life

• This air curtain generates powerful air stream but running quiet

• It is to keep the flying insects out, perfect for office, restaurant, donuts shop or residential door entrance or drive-thru window

• It can be operated at the touch of a button, it has high and low speed switch functions

• This machine adopting optimized electrical machinery, it operates reliably, and runs safely

Product Specification

Brand	Dolphy
Product Type	Air Curtain
Model No.	DACN0005
Dimension (mm)	1200 x 230 x 212
Max. Air Velocity at Nozzle	21 m/s
Noise Level DB	50 - 70 db
Body Material	Metal
Width Size	4 Feet
No. of Blowers	4
No. of Motors	2
HP	0.76
Voltage	220V/50Hz
No. of Shafts	2 Double
Power Wattage	560W
Phase	Single
RPM (Max/Min)	2700 / 2100
Blower Material	ABS
CFM	1100
% Insect / Dust Rejection	75%
Weight Kgs.	22
